PRODUCT FEATURES
- Ultra-reliable Lithium Iron Phosphate Technology.
- High Performance:
- Power output = 5.2kW (continuous)
- Fully rechargeable in 2 hours.
- Robust & Durable:
- Can be discharged to 100% DoD.
- Minimum cycle life > 8000 cycles.
- Safe & Secure:
- Over-charge, over-discharge & short-circuit protection.
- Non-combustible & 100% Recyclable.
- 10 year product warranty
GENERAL SPECIFICATIONS
Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
Nominal Voltage: 51.2V Ah
Rating: 100Ah @C3, 25°C
Installed Capacity @Vnom 5 120Wh
Internal Resistance ≤ 50mΩ @1kHz AC
Serial Communication CAN & RS485
VOLTAGE
Operating Voltage Range 40.0V ~ 57.6V
Bulk Voltage (max.) 57.6V ± 0.3V
Float Voltage (recommended) 54.4V ~ 55.2 V
Low-Voltage (min.) 40.0V
CURRENT
Charge Current (max.) 50A continuous | ≤ 30A recommended
Discharge Current (max.) 100A for 30 mins. | ≤ 70A recommended
Self-discharge Rate Residual capacity: ≤ 3% /month | ≤ 15% /year Recover capacity: ≤ 1.5% /month | ≤ 8% /year
ENVIRONMENTAL REQUIREMENTS
Operating Temperature Range @Charge: 0°C ~ +50°C @Discharge: –10°C ~ +50°C
Recommended Operating Environment Temp. range: +15 ~ +35°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≤ 1 month) Temp. range: –20 ~ +60°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≥ 3 months) Temp. range: +10 ~ +45°C | Humidity: 5 ~ 75%RH
PHYSICAL ATTRIBUTES
Dimensions – Main enclosure 446mm x 435mm x 153mm (W x D x H) *
Dimensions – Front plate 481mm x 153mm (W x H)
Net Weight 46.0kg (unboxed, no accessories)
