Daikin Multi Split Air Conditioning with Perfera Indoor Units
A Daikin Multi Split air conditioner allows multiple indoor air-conditioning units to connect to a single outdoor unit. Instead of installing a separate outdoor condenser for every room, one Daikin Multi Split outdoor unit can provide heating and cooling to several rooms.
Each indoor unit can be controlled individually, so different rooms can be switched on or off and set to their own temperatures. This makes Daikin Multi Split particularly attractive for multi-room homes, guest houses, B&Bs, boutique hotels, apartments and properties where outdoor space or exterior aesthetics are important.
Why choose a Daikin Multi Split system?
The most obvious advantage is simple: fewer outdoor units.
Air-conditioning four rooms with conventional single-split systems can mean four separate outdoor condensers positioned around the property. A Multi Split installation can connect several indoor units to one outdoor system instead.
Daikin Multi Split systems offer several practical advantages:
- Less outdoor space required
- Cleaner building aesthetics with fewer condensers visible outside
- Reduced outdoor noise
- Individual control of each indoor unit
- Different indoor-unit capacities can be selected for different rooms
- Simplified outdoor installation with fewer outdoor units to position and maintain
- Greater flexibility for homes and properties with limited outdoor-unit locations
This can be particularly valuable where you do not want several condensers visible on the outside of a home, where outdoor wall or courtyard space is limited, or where several guest bedrooms require individual air conditioning without an outdoor unit outside every room.
Choose your Daikin Multi Split outdoor unit
EcoHub offers three Daikin Multi Split outdoor-unit options:
| Daikin Outdoor Unit | Nominal Cooling Capacity | Maximum Indoor Units |
|---|---|---|
| 3MXM68A9 | 6.8 kW | Up to 3 |
| 4MXM80A9 | 8.0 kW | Up to 4 |
| 5MXM90A9 | 9.0 kW | Up to 5 |
Does a 5MXM90A9 have to be connected to five indoor units?
No. “Up to five” is the maximum number of indoor units that can be connected; it does not mean that five indoor units must be installed.
The same applies to the 3MXM and 4MXM models. The correct outdoor unit should be selected according to both the number of indoor units and the amount of cooling or heating capacity likely to be required at the same time.
This means that choosing the larger 5MXM90A9 can make sense even when fewer than five indoor units are planned.
Why simultaneous usage matters
A useful way to think about Multi Split sizing is to consider how the building will actually be used.
Example: bedrooms in a guest house
Imagine three air-conditioned guest bedrooms. Although there are only three indoor units, all three rooms may be occupied on the same summer evening. It is therefore quite possible for all three air conditioners to require significant cooling at the same time.
In an application like this, available outdoor-system capacity under simultaneous load becomes particularly important. It may make sense to select a larger outdoor unit rather than simply choosing the smallest model capable of accepting three indoor connections.
This is one reason Multi Split can be particularly attractive for guest houses and boutique accommodation: each guest room retains individual temperature control while several rooms share a much neater outdoor installation.
Example: living areas during the day and bedrooms at night
A residence can have a very different usage pattern.
A large Perfera indoor unit may serve the living area during the afternoon and evening, while smaller Perfera units serve bedrooms primarily at night.
The home may therefore have considerable installed indoor capacity, but the maximum demand from every room is unlikely to occur simultaneously.
During the day, the living-room air conditioner may carry most of the cooling load while the bedrooms are unused. At night, the living-room unit may be switched off while the bedroom units operate.
This is known as load diversity. It is an important consideration when designing a Multi Split system because the total capacity of all connected indoor units does not necessarily represent the amount of cooling that will be required simultaneously.
Example: home office plus bedrooms
Another common configuration may include a home office used during working hours together with bedroom air conditioners used predominantly at night.
Again, the different spaces need correctly sized indoor units, but their peak loads occur at different times. A properly designed Multi Split system can take advantage of this usage pattern.
The final combination must always fall within Daikin’s approved indoor/outdoor unit combinations and installation requirements.
Premium Daikin Perfera indoor units
This EcoHub Multi Split configuration uses Daikin Perfera wall-mounted indoor units.
Perfera is Daikin’s high-performance wall-mounted range, combining premium heating and cooling with advanced comfort, airflow and air-quality features. It is therefore particularly well suited to premium residential, guest-house and boutique accommodation installations.
Available Perfera indoor-unit capacities include:
- 9,000 BTU – FTXM25R
Suitable for appropriately sized bedrooms and smaller rooms. - 12,000 BTU – FTXM35R
A popular choice for bedrooms and medium-sized spaces. - 18,000 BTU – FTXM50R
For larger bedrooms, offices and living areas. - 20,000 BTU – FTXM60R
For larger spaces with higher heating or cooling requirements. - 24,000 BTU – FTXM71A
The largest Perfera indoor unit in this selection, suitable for larger living areas and rooms requiring substantially greater capacity.
Individual comfort in every room
One outdoor unit does not mean that all of the indoor units have to operate together.
Each connected indoor unit can be controlled separately. A bedroom can therefore be switched off while the living room operates, or different occupied rooms can have different temperature settings.
Connected indoor units do, however, operate within the same overall system mode. They can operate in cooling mode or heating mode, but one connected indoor unit cannot actively cool while another indoor unit on the same Multi Split outdoor system is simultaneously heating.
A cleaner solution for multi-room air conditioning
For many properties, the real attraction of Multi Split is not simply technical efficiency. It is the ability to provide individual air conditioning in several rooms without surrounding the building with outdoor condensers.
This makes Daikin Multi Split particularly worth considering for:
Premium residences
Air-condition several rooms while keeping exterior walls, courtyards and entertainment areas cleaner and less cluttered.
Guest houses and B&Bs
Provide individual comfort for guest rooms while reducing the number of outdoor condensers positioned around guest areas.
Boutique hotels and accommodation properties
An attractive solution for smaller hospitality properties where quiet operation, individual room control and the appearance of the building are important considerations.
Apartments and townhouses
Useful where balcony space, external walls or permitted outdoor-unit locations are limited.
Renovations and architecturally sensitive homes
Air-condition several rooms while minimising the visual impact of mechanical equipment on the building.
Which Daikin Multi Split system should I choose?
There is not a simple rule that says:
3 rooms = 3MXM
4 rooms = 4MXM
5 rooms = 5MXM
The numbers indicate the maximum number of indoor-unit connections.
The correct outdoor unit also depends on:
- The size and heat load of each room
- The capacities of the selected Perfera indoor units
- How many indoor units are likely to operate simultaneously
- Whether different areas of the property are generally used at different times
- Daikin’s approved indoor/outdoor combinations
- Refrigerant pipe lengths and installation requirements
A larger outdoor unit can therefore sometimes be the better choice even when you do not intend to use every available indoor connection.
Frequently Asked Questions
What is a Daikin Multi Split air conditioner?
A Daikin Multi Split system connects multiple indoor air-conditioning units to one outdoor unit. Each indoor unit can serve a different room and can be controlled individually.
Can one outdoor air conditioner run several indoor units?
Yes. Daikin Multi Split systems are specifically designed for this purpose. The 3MXM68A9 can connect up to 3 indoor units, the 4MXM80A9 up to 4, and the 5MXM90A9 up to 5.
Do I have to connect five indoor units to a 5MXM90A9?
No. Five is the maximum number of indoor units. A 5MXM90A9 can be used with fewer indoor units where the particular system configuration or expected simultaneous load makes the larger outdoor unit appropriate.
Can every room have a different temperature?
Yes. Each indoor unit can be individually controlled, allowing different occupied rooms to have different temperature settings.
Is Multi Split suitable for a guest house?
Multi Split can be particularly well suited to guest houses, B&Bs and boutique accommodation where several guest rooms need individual air conditioning but the owner wants to minimise the number of outdoor condensers around the property.
Why choose Multi Split instead of several normal split air conditioners?
The main advantage is the ability to air-condition several rooms while using substantially fewer outdoor units. This can save outdoor space, reduce exterior clutter and create a cleaner installation.
Need help designing your Daikin Multi Split system?
Contact EcoHub for assistance selecting the correct Daikin Multi Split outdoor unit and Perfera indoor units for your property.
Tell us which rooms you would like to air-condition, their approximate sizes and how the property is normally used. We can help you determine an appropriate Daikin Multi Split configuration before you order.
Daikin Multi Split Information
For further technical information, see Daikin South Africa’s Multi Split air-conditioning information.
