Hubble AM2 Brochure Hubble AM2 Warrany
Hubble AM2 Lithion Ion Battery Features
- Low self discharge
- High cycle and service life
- Easy wall mount or shelf rack installation
- Excellent high temperature performance
- Advanced BMS with current limiting function
- Compatible with most inverters and chargers
- High energy density and conversion efficiency
- Cloudlink integration ready for wifi monitoring
- Complete with integrated Battery Management System
- Heavy duty side handles for easy handling and mounting on the wall
- Built in protection for over-charge, over-discharge & over-temperature
- CAN Bus, fully integrates and communicates with leading Inverter brands
Technical Specifcations
Rated Capacity (5HR): 116Ah
Nominal Voltage: 48V
Design Capacity: 5.5kWh
Equalised Charge Voltage: 53.8V
Max. Continuous Charging Current: 105A
Max. Continuous Discharging Current: 105A
C Rating: 1.0C
Weight: Approx. 42kg
Display: None
Parallel: Parallel connection up to 15 packs with full communications
Dimensions (WxDxH): 375mm x 145mm x 467mm
Ports: 1 x CAN-bus, 2 x Battery Link Ports
Cells: New Li-ion Prismatic Cells (LifePO4)
Design Life: ± 15 years
Cycle Life @ 1C: +/- 6000 cycles @ 50% DOD, Above 3000 cycles @ 100% DOD
Certification: CE, UN38.2, GBT31484-2015, GBT31485-2015, GBT31486-2015
Outer Package Material: White Bake Lacquer Steel Case
Operating Temperature
Charging: 0°C to 55°C
Discharging: -20°C to +55°C
Storage: -20°C to +55°C
Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting
